1.1This test method covers the quantitative analysis of in-service lubricants using an automatic testing device that integrates these varied technologies: atomic emission spectroscopy, infrared spectroscopy, viscosity, and particle counting.
1.2This is suited for in-service lubricating oils having viscosities in the range between ISO 10 and ISO 320 and properties in the ranges given in Tables 1 and 2.
| Element | Low Range, mg/kg | High Range, mg/kg | Element | Low Range, mg/kg | High Range, mg/kg |
| Aluminum | 5 to 100 | NA | Molybdenum | 10 to 1000 | NA |
| Barium | 25 to 150 | 150 to 2000 | Nickel | 5 to 100 | NA |
| Boron | 5 to 100 | 100 to 1000 | Phosphorous | 100 to 600 | 600 to 4000 |
| Calcium | 25 to 500 | 500 to 9000 | Potassium | 10 to 1000 | 1000 to 4000 |
| Chromium | 8 to 100 | NA | Silicon | 5 to 150 | 150 to 3000 |
| Copper | 5 to 500 | 500 to 1000 | Sodium | 10 to 1000 | NA |
| Iron | 6 to 1000 | 1000 to 3000 | Tin | 6 to 100 | NA |
| Lead | 6 to 150 | NA | Titanium | 8 to 100 | NA |
| Magnesium | 5 to 100 | 100 to 3000 | Vanadium | 7 to 100 | NA |
| Manganese | 5 to 100 | NA | Zinc | 8 to 100 | 100 to 4000 |
Note 1:Review Test Method D4739 and D2896 for particular lubricating oil applications.
| Physical Property | Range |
| Water, % by mass | 0.1 to 3 |
| Glycol, % by mass | 0.1 to 2 |
| Soot, % by mass | 0.1 to 4 |
| Fuel Dilution, % by mass | 0.1 to 15 |
| Oxidation, abs. | 0.1 to 50 |
| Nitration, abs. | 0.1 to 35 |
| Calculated Viscosity - IR | 4 to 35 (100° cSt) |
| Viscosity 40 °C, cSt (optional) | 30 to 320 |
| Viscosity 100 °C, cSt (optional) | 5 to 25 |
| Viscosity Index | 5 to 150 |
| Base Number, mg/g KOH | 1.0 to 17 |
