  • IEC 60191-6-22 Ed. 1.0 b:2012

IEC 60191-6-22 Ed. 1.0 b:2012

Mechanical standardization of semiconductor devices - Part 6-22: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - Design guide for semiconductor packages Silicon Fine-pitch Ball Grid Array and Silicon Fine-pitch Land Grid Array (S-FBGA and S-FL

International Electrotechnical Commission , 12/11/2012

Publisher: IEC

File Format: PDF

$72.00$145.00


IEC 60191-6-22:2012 provides the outline drawings and dimensions common to silicon-based package structures and materials of ball grid array packages (BGA) and land grid array packages (LGA).

Published: 12/11/2012

Pages: 34

File Size: 1 file , 380 KB

Language: English, French

Note: This product is unavailable in Ukraine, Russia, Belarus
