IEC 60917-2-5 Ed. 1.0 b:2012

Modular order for the development of mechanical structures for electronic equipment practices - Part 2-5: Sectional specification - Interface co-ordination dimensions for the 25 mm equipment practice - Cabinet interface dimensions for miscellaneous equipment

International Electrotechnical Commission , 07/24/2012

Publisher: IEC

File Format: PDF

$72.00$145.00

Description

IEC 60917-2-5:2012 applies to a frame-based cabinet structure with the specification of interface dimensions for the installation of miscellaneous equipment. The frame structure provides the mounting planes with mounting points for the assembly of internal and external accessories. Unlike the existing standards IEC 60917-2-1 and IEC 60297-3-100, this standard allows cover parts like top covers and front/rear doors to exceed the cabinet's external coordination dimensions. Keywords: Modular cabinet, cabinet mounting, frame-based

Published: 07/24/2012

Pages: 37

File Size: 1 file , 340 KB

Language: English, French

Note: This product is unavailable in Ukraine, Russia, Belarus
