This International Standard applies to self-commutated converter valves, for use in a threephase bridge voltage sourced converter (VSC) for high voltage DC power transmission or as part of a back-to-back link, and to dynamic braking valves. It is restricted to electrical type and production tests.

This document can be used as a guide for testing of high-voltage VSC valves used in energy storage systems (ESS).

The tests specified in this document are based on air insulated valves. The test requirements and acceptance criteria can be used for guidance to specify the electrical type and production tests of other types of valves.

The following documents are referred to in the text in such a way that some or all of their content constitutes requirements of this document. For dated references, only the edition cited applies.

For undated references, the latest edition of the referenced document (including any amendments) applies.

IEC 60060 (all parts), High-voltage test techniques

IEC 60071 (all parts), Insulation co-ordination

IEC 60270, High-voltage test techniques – Partial discharge measurements

IEC 60700-1:2015, Thyristor valves for high voltage direct current (HVDC) power transmission

– Part 1: Electrical testing

IEC 60700-1:2015/AMD1:2021

IEC 62747, Terminology for voltage-sourced converters (VSC) for high-voltage direct current (HVDC) systems

ISO/IEC 17025, General requirements for the competence of testing and calibration laboratories
