IEC 62946-01 Ed. 1.0 en:2018

Connectors for electrical and electronic equipment - Part 01: Rectangular connectors - Detail specification for 8-way, shielded, free and fixed high density connectors for data transmission with frequencies up to 100 MHz and with current carring capacity up to 1A

International Electrotechnical Commission , 05/24/2018

Publisher: IEC

File Format: PDF

$117.00$234.00

Description

IEC 62946-01:2018(E) covers 8-way shielded connectors, and is intended to specify the common dimensions, mechanical, electrical and environmental characteristics and tests for the family of IEC 62946-01 connectors.
These connectors are intermateable and interoperable with other IEC 62946 series connectors.
Key words: Connectors, Rectangular, 8-way, Shielded Free and Fixed High density, Data Transmission

Published: 05/24/2018

Pages: 29

File Size: 1 file , 720 KB

Language: English

Note: This product is unavailable in Ukraine, Russia, Belarus
