The aim of this specification is to create a state-of-the-art communication protocol for handling board transfers and associated data at surface-mount technology (SMT) production lines. Therefore, this new communication protocol has to cope with the following:

• Replace the electrical SMEMA interface as specified in IPC-SMEMA-9851

• Extend the interface to communicate:

– Unique identifiers for the handled printed circuit boards (PCBs)

– Equipment identifiers of the first machine noticing a PCB

– Barcodes

– Conveyor speed and intended board route

– A lightweight digital twin of the product containing, e.g.,

▪ Product type identifier

▪ Length

▪ Width

▪ Thickness

▪ Board state

With respect to version numbers The Hermes Standard adheres to the rules of Semantic Versioning 2.0.0 [SemVer_2.0.0].

Hints on naming:

• Wherever a feature is described by the word “shall” it is mandatory.

• The word “machine” is used for any equipment which can be found in a SMT production line (e.g., printers, placement machines, ovens, AOIs, transport modules, shuttles, stackers).

• The term “PCB” may also refer to carriers transporting PCBs.

• The word “Hermes” is used as abbreviation for “The Hermes Standard”.

• “The Hermes Standard” and IPC-HERMES-9852 are synonyms for the standard specified in this document and might be used interchangeably.
