BS PD CLC/TS 50459-1:2015

BS PD CLC/TS 50459-1:2015 describes from an ergonomic point of view how ERTMS and non-ERTMSinformation will be arranged and displayed. More specifically, it covers information that is out of thescope of ERA_ERTMS_015560. This Technical Specification describes more ergonomic details thancurrently provided by the ERTMS/GSM-R specifications.This Technical Specification defines the ergonomics for the Driver-Machine Interface (DMI) for thefollowing applications:

• stand-alone ERTMS/GSM-R Train Radio Systems;
• non-ERTMS/ETCS Train Control Systems;
• other technical systems currently provided on the rolling stock.

The ergonomics covers

• the general arrangements (dialogue structure, sequences, layout philosophy, colour philosophy),
• the symbols,
• the audible information,
• the data entry arrangements.

This Technical Specification is limited to ergonomic considerations and does not define the technologyto be used for the implementation but it does give guidelines about how to implement the requirementsusing different technology types (soft keys, touch screen device, LCD, electromechanical instruments,indicator lamps, etc.).This Technical Specification is applicable to all trains fitted with the ERTMS/ETCS and also to trainsfitted with train radio (GSM-R) DMI.The scope of Part 1 of CLC/TS 50459 is to define ergonomic principles for the interface between thedriver and the above listed applications.TDD is out of scope of CLC/TS 50459 series.For human factor items, such as display of information, display location, viewing angles andorganization of the screens, see EN 16186 series.Cross References:ERA_ERTMS_015560EN 16186-1prEN 16186-2:2015prEN 16186-3 CLC/FprTS 50459-2CLC/FprTS 50459-3EN 894-2EN ISO 9241-302:2008ISO 9241-302:2008EN ISO 9241-303:2011ISO 9241-303:2011EN ISO 9241-304:2008ISO 9241-304:2008EN ISO 9241-305:2008ISO 9241-305:2008EN ISO 9241-307:2008ISO 9241-307:2008EN ISO 9241-400:2007ISO 9241-400:2007EN ISO 9241-420:2011ISO 9241-420:2011EN ISO 6385:2004ISO 6385:2004EN ISO 9241-110:2006ISO 9241-110:2006EN ISO 9241-12ISO 9241-12 ISO 9355-1:1999ISO 9355-2:1999UIC 612-0UIC 612-01UIC 640UIC 651UIC CODE 950-7.3.0UIC CODE 951-15.3.0ERTMS/ETCS Class 1 SRS Subset-026
