IEC 62424:2008 specifies how process control engineering requests are represented in a P&ID for automatic transferring data between P&ID and PCE tool and to avoid misinterpretation of graphical P&ID symbols for PCE. It also defines the exchange of process control engineering request relevant data between a process control engineering tool and a P&ID tool by means of a data transfer language (called CAEX). These provisions apply to the export/import applications of such tools. It cancels and replaces IEC/PAS 62424 published in 2005. This first edition constitutes a technical revision.
IEC 62424 Ed. 1.0 b:2008 History
IEC 62424 Ed. 2.0 b:2016
$256.00 $512.00
IEC 62424 Ed. 1.0 b:2008
$193.00 $387.00
IEC 62424 Ed. 1.0 en:2008
$161.00 $322.00
