IEEE 1018-2004

This recommended practice establishes requirements for three-conductor new round-and-flat-type oil-well cables used in supplying three-phase ac electric power to submersible pump motors. The three major cables by components are copper conductors, ethylene-propylene diene monomer (EPDM) insulation, nitrile jacket and galvanized armor. Perform 5 year review and updates for advances in submersible pump cable technology. Revision Standard - Superseded. Minimum requirements for the construction, manufacturing, purchasing, and application of electric submersible pump cable are presented. The cable is round or flat, with ethylene- propylene rubber insulation, nitrile jacket, ethylene-propylene diene monomer (EPDM) jacket or lead sheath, and armor. These cables are for voltages not exceeding 3 kV or 5 kV (phase to phase) and conductor temperatures not exceeding 140 ºC (284 ºF) for nitrile or a maximum of 204 ºC (400 ºF) for EPDM jacket or lead sheath cable. Conductors, insulation, barrier (optional), assembly and jacket, armor, requirements for testing by the manufacturer, and cable ampacity are covered.
