IPC 7525B:2011

Stencil Design Guidelines

Association Connecting Electronics Industries , 10/01/2011

Publisher: IPC

File Format: PDF

$50.00$101.00


This document provides guidelines for the design and fabrication of stencils for solder paste and surface mount adhesive with discussion on through-hole and mixed technology. This includes differences for tin lead and lead-free solder paste, overprint, two-print and step stencil designs. A sample order form and user inspection checklist are also included.
